Description
The B-7PSM from Nu-X is the ultimate in wireless in-ear monitoring, with uber-sleek design and functionality.
This is the ideal tool for in-ear stage performance, and with a massive 30m (unobstructed) operation range and over 4 hours of battery life you can feel secure with your tone on any stage! The receiver includes comfort-fit earphones with smart ear-wrap design to ensure stability, plus the easy set-up and pairing makes the B-7PSM a breeze to use. It also features stereo audio transmission, allowing you to pan instruments in stereo to create your own perfect personal mix.
Offering a massive 20Hz-19kHz frequency response with minimal latency, this is a great wireless in-ears option for any level of performance. The 5.8GHz bandwidth allows for up to 10 units to be used in conjunction, so the whole band is covered! With other Nu-X wireless devices operating at 2.4GHz you can have up to 16 units in operation together.
It quickly finds a clean wireless channel and automatically assigns it. The B-7PSM offers a super low latency of less than 5.5ms and has an operation range of 100 feet (30m) when unobstructed between the Receiver (RX) and Transmitter (TX). (The operation range is around 32 feet (10m) when obstructed). It’s a super light-weight wireless, mini-compact system designed to clip on & go. The TX features a 1/8” TRS plug (you can use the included adaptor to convert to 1/4”), broadcaster-grade audio via 5.8GHz digital transmission to the compact RX. The RX’s clip design can easily fit to your shirt, belt, or guitar strap. And, with our newest automatic frequency hopping technology, B-7PSM is reliable and stable while you perform on stage.
Specifications
- Output Volume Adjustment
-64dB~0dB (0.5dB step)
- Operating Frequency Band
5.8 GHz
- Operation Length
< 100 feet (30m) outdoor unobstructed, < 33 feet (10m) outdoor with obstructions
- Sampling Rate
24bit / 40 kHz
- Frequency Response
20~19kHz
- Latency
< 5.5ms
- Dynamic Range
92 dB
- THD+ Noise
<0.6%@1kHz
- Built-in Battery Capacity (TX & RX)
450mAh / 3.7V
- Battery Running Time
> 4 hours
- Battery Charging Time
around 1.5 hours
- Power Consumption
TX <90mA，RX < 45mA
- TX Impedance
3.5kΩ
- Maximum Input Level
7.6Vpp (8.6dBV or 2.7Vrms)
- RX Suggestion Phone Impedance
16~32Ω
- Maximum Output Power
57mWrms (RLOAD =16Ω, 1 kHz).
